Agricultural Fittings

Truwell offers a vast range of pvc pipes as per ISI standard with sizes ranging from 20 mm to 315 mm. They are extensively used for potable water transportation, drainage and irrigation purposes. With stand temperature at 1 to 450 C

Standards

Features

Easy handling and installation

Transportation friendly

Durable and strong

Corrosion resistance

Long lasting

Cost worthy at reasonable price

UV stabilise

Prevents clogging

Light weight

Applications

In agricultural field for tube well and borewell purpose, used as drainage in residential, industrial and commercial buildings, also used in swimming pools and domestic water supply.

Dimension Of PVC Pipes

All dimensions in millimeters & inches BIS 4985 2000 (extract) wall thickness for working pressure

OUTSIDE DIAMETER	TOLERANCE ON OUTSIDE DIAMETER	CLASS 2 4kgf / CM2		CLASS 3 6kgf / CM2		CLASS 5 10kgf / CM2
		MIN	MAX	MIN	MAX	MIN	MAX
20mm (1/2")	+0.3	-	-	-	-	1.1	1.5
25mm (3/4")	+0.3	-	-	-	-	1.4	1.8
32mm (1")	+0.3	-	-	-	-	1.8	2.2
40mm (1 ¼”)	+0.3	-	-	1.4	1.8	2.2	2.7
50mm (1 ½”)	+0.3	-	-	1.7	2.1	2.8	3.3
63mm (2”)	+0.3	1.5	1.9	2.2	2.7	3.5	4.1
75mm (2 ½”)	+0.3	1.8	2.2	2.6	3.1	4.2	4.9
90mm (3”)	+0.3	2.1	2.6	3.1	3.7	5.0	5.7
110mm (4”)	-0.5	2.5	3.0	3.7	4.3	6.1	7.1
140mm (5”)	+0.5	3.5	3.8	4.8	5.5	7.7	8.9
160mm (6”)	+0.5	3.7	4.3	5.4	6.2	8.8	10.2
180mm (7”)	+0.6	4.3	4.9	6.1	7.1	9.9	11.4
200mm (8”)	+0.6	4.6	5.3	6.8	7.9	11.0	12.7
225mm (9 ”)	+0.7	5.2	6.0	7.6	8.8	12.4	14.3
250mm (10”)	+0.7	5.7	6.5	8.5	9.8	13.8	15.9
280mm (11”)	+0.7	6.4	7.4	9.5	11.0	15.4	17.8
315mm (12”)	+0.7	7.2	8.3	10.7	12.4	17.3	19.9

Agricultural Fittings

We are enlisted as a leading manufacturer and supplier of PVC fittings. These fittings are manufactured by making use of excellent quality material in adherence to set industrial norms. Also, our fittings are widely trusted for laying pipe lines of water main supply and micro and macro irrigation.
