CPVC Piping System
Chlorinated polyvinyl chloride (CPVC) is a thermoplastic used for hot and cold water lines across the world for more than 50 years, making it the first choice of material for potable water supply globally. It is ideal for hot and cold water applications in villas, individual homes, apartments, offices, commercial buildings, hotels, and hospitals. Truwell CPVC pipes are manufactured from eco-friendly CPVC compound, ensuring they are safe for drinking water.
Features & Benefits
Applications
Residential
Commercial
Hospital
Hotel
Industrial Units
Specification
| Nominal Size | Mean Outside Diameter | Wall thickness | Working Pressure | ||
|---|---|---|---|---|---|
| Min | Max | At 27° C | At 82° C | ||
| 15 (1/2) | 15.80 - 16.00 | 1.70 | 2.20 | 28.14 Kg/cm² | 6.93 Kg/cm² |
| 20 (3/4) | 22.10 - 23.30 | 2.00 | 2.50 | 28.14 Kg/cm² | 6.93 Kg/cm² |
| 25 (1) | 28.50 - 28.70 | 2.60 | 3.10 | 28.14 Kg/cm² | 6.93 Kg/cm² |
| 32 (1 1/4) | 34.80 - 35.00 | 3.20 | 3.70 | 28.14 Kg/cm² | 6.93 Kg/cm² |
| 40 (1 1/2) | 41.20 - 41.40 | 3.80 | 4.30 | 28.14 Kg/cm² | 6.93 Kg/cm² |
| 50 (2) | 53.90 - 54.10 | 4.90 | 5.50 | 28.14 Kg/cm² | 6.93 Kg/cm² |
| Nominal Size | Mean Outside Diameter | Wall thickness | Working Pressure | |||
|---|---|---|---|---|---|---|
| Min (mm) | Max (mm) | Min (mm) | Max (mm) | At 27°C (Kg/cm²) | At 82°C (Kg/cm²) | |
| 15 (1/2") | 15.80 | 16 | 1.40 | 1.90 | 22.22 | 5.60 |
| 20 (3/4") | 22.10 | 23.30 | 1.70 | 2.20 | 22.22 | 5.60 |
| 25 (1") | 28.50 | 28.70 | 2.10 | 2.60 | 22.22 | 5.60 |
| 32 (1 1/4") | 34.80 | 35.00 | 2.60 | 3.10 | 22.22 | 5.60 |
| 40 (1 1/2") | 41.20 | 41.40 | 3.10 | 3.60 | 22.22 | 5.60 |
| 50 (2") | 53.90 | 54.10 | 4.00 | 4.60 | 22.22 | 5.60 |
CPVC Fittings
Solvent Cement
Ball Valve
Brass Elbow
Brass Tee
Brass MTA
Brass FTA
Pain Elbow
Plain MTA
Plain FTA
Coupler
End Cap
Union
Tank Nipple
Reducer
Reducer Bush
Reducer Tee
Gross Tee
Step Over
Metal Clamp
Long Plug
